DMP68D1LVQ-7
Diodes Incorporated
Package: Tape & Reel (TR)
Description: MOSFET 2P-CH 60V 0.238A SOT563
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 500mW (Ta) |
| Configuration | 2 P-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | SOT-563, SOT-666 |
| Vgs(th) (Max) @ Id | 2.1V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 8Ohm @ 100mA, 5V |
| Supplier Device Package | SOT-563 |
| Gate Charge (Qg) (Max) @ Vgs | 0.6nC @ 5V |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 42pF @ 30V |
| Current - Continuous Drain (Id) @ 25°C | 238mA (Ta) |
