G170P03S2
Goford Semiconductor
Package: Tape & Reel (TR)
Description: MOSFET P+P-CH 30V 11A SOP-8 DUAL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Technology | MOSFET (Metal Oxide) |
|---|---|
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 18mOhm @ 5A, 10V |
| Supplier Device Package | 8-SOP |
| Gate Charge (Qg) (Max) @ Vgs | 40nC @ -10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 1786pF @ -15V |
| Current - Continuous Drain (Id) @ 25°C | 11A (Tc) |
