SI3439KDWAS-TP
MCC (Micro Commercial Components)
Package: Tape & Reel (TR)
Description: DUAL N/P-CHANNEL MOSFET,SOT-363S
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 325mW (Tj) |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 1.1V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 300mOhm @ 500mA, 4.5V, 850mOhm @ 500mA, 4.5V |
| Supplier Device Package | SOT-363S |
| Gate Charge (Qg) (Max) @ Vgs | 1.2nC @ 10V |
| Drain to Source Voltage (Vdss) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 28pF @ 16V, 36pF @ 16V |
| Current - Continuous Drain (Id) @ 25°C | 750mA (Ta), 600mA (Ta) |
