MC7252KDWA-TP
MCC (Micro Commercial Components)
Package: Tape & Reel (TR)
Description: MOSFET N/P-CH 60V 0.34A SOT363
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 150mW |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA, 2V @ 250μA |
| Operating Temperature | -55°C ~ 150°C |
| Rds On (Max) @ Id, Vgs | 5Ohm @ 500mA, 10V, 8Ohm @ 100mA, 10V |
| Supplier Device Package | SOT-363 |
| Gate Charge (Qg) (Max) @ Vgs | - |
| Drain to Source Voltage (Vdss) | 60V, 50V |
| Input Capacitance (Ciss) (Max) @ Vds | 40pF @ 10V, 30pF @ 5V |
| Current - Continuous Drain (Id) @ 25°C | 340mA, 180mA |
