RGW40TK65DGVC11
ROHM Semiconductor
Package: Tube
Description: IGBT TRENCH FS 650V 27A TO-3PFM
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 59 nC |
| Part Status | Active |
| Power - Max | 61 W |
| Mounting Type | Through Hole |
| Package / Case | TO-3PFM, SC-93-3 |
| Test Condition | 400V, 20A, 10Ohm, 15V |
| Switching Energy | - |
| Td (on/off) @ 25°C | 33ns/76ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-3PFM |
| Vce(on) (Max) @ Vge, Ic | 1.9V @ 15V, 20A |
| Reverse Recovery Time (trr) | 92 ns |
| Current - Collector (Ic) (Max) | 27 A |
| Current - Collector Pulsed (Icm) | 80 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
