RGA80TSX2HRC11
ROHM Semiconductor
Package: Tube
Description: IGBT TRENCH FS 1200V 105A TO247N
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| IGBT Type | Trench Field Stop |
| Input Type | Standard |
| Gate Charge | 259 nC |
| Part Status | Not For New Designs |
| Power - Max | 468 W |
| Mounting Type | Through Hole |
| Qualification | AEC-Q101 |
| Package / Case | TO-247-3 |
| Test Condition | 800V, 40A, 10Ohm, 15V |
| Switching Energy | 2.58mJ (on), 3.31mJ (off) |
| Td (on/off) @ 25°C | 94ns/344ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247N |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 40A |
| Current - Collector (Ic) (Max) | 105 A |
| Current - Collector Pulsed (Icm) | 120 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
