PTGH7565S1_T0_00201
Panjit International Inc.
Package: Cut Tape (CT)
Description: IGBT TRENCH FS 650V 133A TO247L
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| IGBT Type | Trench Field Stop |
| Input Type | Standard |
| Gate Charge | 108 nC |
| Part Status | Active |
| Power - Max | 366 W |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 75A, 10Ohm, 15V |
| Switching Energy | 2.47mJ (on), 1.27mJ (off) |
| Td (on/off) @ 25°C | 30ns/137ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO247-3L |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 75A |
| Reverse Recovery Time (trr) | 57 ns |
| Current - Collector (Ic) (Max) | 133 A |
| Current - Collector Pulsed (Icm) | 225 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
