AFGHL25T120RWD
onsemi
Package: Tube
Description: IGBT TRENCH FS 1200V 50A TO-247
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| IGBT Type | Trench Field Stop |
| Input Type | Standard |
| Gate Charge | 113 nC |
| Part Status | Active |
| Power - Max | 468 W |
| Mounting Type | Through Hole |
| Qualification | AEC-Q101 |
| Package / Case | TO-247-3 |
| Test Condition | 600V, 25A, 4.7Ohm, 15V |
| Switching Energy | 1.57mJ (on), 1.06mJ (off) |
| Td (on/off) @ 25°C | 36.9ns/175ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247-3 |
| Vce(on) (Max) @ Vge, Ic | 1.71V @ 15V, 25A |
| Reverse Recovery Time (trr) | 173 ns |
| Current - Collector (Ic) (Max) | 50 A |
| Current - Collector Pulsed (Icm) | 75 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
