NVMFWD040N10MCLT1G
onsemi
Package: Cut Tape (CT)
Description: PTNG 100V LL SO8FL DUAL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 3.2W (Ta), 36W (Tc) |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 3V @ 26μA |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 39mOhm @ 5A, 10V |
| Supplier Device Package | 8-DFN (5x6) Dual Flag (SO8FL-Dual) |
| Gate Charge (Qg) (Max) @ Vgs | 8.4nC @ 10V |
| Drain to Source Voltage (Vdss) | 100V |
| Input Capacitance (Ciss) (Max) @ Vds | 520pF @ 50V |
| Current - Continuous Drain (Id) @ 25°C | 6.1A (Ta), 21A (Tc) |
