NVMFS5C430NLWFHT1G
onsemi
Package: Cut Tape (CT)
Description: T6 40V NCH LL IN SO8FL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| FET Type | N-Channel |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount, Wettable Flank |
| Qualification | AEC-Q101 |
| Package / Case | 8-PowerTDFN, 5 Leads |
| Vgs(th) (Max) @ Id | 2V @ 250μA |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 1.4mOhm @ 50A, 10V |
| Power Dissipation (Max) | 3.8W (Ta), 110W (Tc) |
| Supplier Device Package | 5-DFNW (4.9x5.9) (8-SOFL-WF) |
| Gate Charge (Qg) (Max) @ Vgs | 70 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 40 V |
| Input Capacitance (Ciss) (Max) @ Vds | 4300 pF @ 20 V |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 38A (Ta), 200A (Tc) |
