MCACD40NP03-TP
MCC (Micro Commercial Components)
Package: Tape & Reel (TR)
Description: MOSFET N/P-CH 30V 40A 8PDFN
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 50W (Tj), 54W (Tj) |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerLDFN |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA, 2.7V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 9mOhm @ 20A, 10V, 12mOhm @ 20A, 10V |
| Supplier Device Package | PDFN5060-8D |
| Gate Charge (Qg) (Max) @ Vgs | 23.6nC @ 10V, 38nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 1050pF @ 15V, 1860pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Tc) |
