IXYN180N65A5
IXYS
Package: Bulk
Description: 650V, 180A, XP Gen5 A5 IGBT in S
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Active |
| Power - Max | 940 W |
| Configuration | Single |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | SOT-227-4, miniBLOC |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | SOT-227B |
| Vce(on) (Max) @ Vge, Ic | 1.35V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 340 A |
| Input Capacitance (Cies) @ Vce | 8640 pF @ 25 V |
| Current - Collector Cutoff (Max) | 25 μA |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
