MSCGLQ75DDU120CTBL3NG
Microchip Technology
Package: Bulk
Description: PM-IGBT-SBD-BL3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Active |
| Power - Max | 470 W |
| Configuration | Full Bridge |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | - |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 75A |
| Current - Collector (Ic) (Max) | 160 A |
| Input Capacitance (Cies) @ Vce | 4.4 nF @ 25 V |
| Current - Collector Cutoff (Max) | 50 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
