DI018C03PT
Diotec Semiconductor
Package: Bulk
Description: MOSFET N/P-CH 30V 27A 8QFN
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 10.8W (Tc) |
| Configuration | N and P-Channel |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerVDFN |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 9.3mOhm @ 15A, 10V, 30.1mOhm @ 10A, 10V |
| Supplier Device Package | 8-QFN (3x3) |
| Gate Charge (Qg) (Max) @ Vgs | 12nC @ 4.5V, 20nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 1122pF @ 15V, 1150pF @ 20V |
| Current - Continuous Drain (Id) @ 25°C | 27A (Tc), 18A (Tc) |
