PMEG6010EXD-QX
Nexperia USA Inc.
Package: Cut Tape (CT)
Description: PMEG6010EXD-Q/SOD323HP/SO2
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | 2-SMD, Flat Leads |
| Capacitance @ Vr, F | 74pF @ 1V, 1MHz |
| Supplier Device Package | SOD323HP |
| Reverse Recovery Time (trr) | 5.4 ns |
| Current - Reverse Leakage @ Vr | 50 μA @ 60 V |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Current - Average Rectified (Io) | 1A |
| Operating Temperature - Junction | 175°C |
| Voltage - Forward (Vf) (Max) @ If | 580 mV @ 1 A |
