MPQ7091
onsemi
Package: Bulk
Description: TRANS 4PNP 150V 500MA 14PDIP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 750mW |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Transistor Type | 4 PNP (Quad) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Frequency - Transition | 70MHz |
| Supplier Device Package | 14-PDIP |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 2mA, 20mA |
| Current - Collector (Ic) (Max) | 500mA |
| Current - Collector Cutoff (Max) | 250nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 35 @ 10mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 150V |
