LDR31850
Powerex Inc.
Package: Bulk
Description: SCR MODULE 1.8KV 785A POW-R-BLOK
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Series Connection - SCR/Diode |
|---|---|
| Part Status | Discontinued at |
| Mounting Type | Chassis Mount |
| Package / Case | POW-R-BLOK? Module |
| Voltage - Off State | 1.8 kV |
| Operating Temperature | -40°C ~ 130°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs |
| Current - Hold (Ih) (Max) | 300 mA |
| Current - Gate Trigger (Igt) (Max) | 250 mA |
| Current - On State (It (AV)) (Max) | 500 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Current - On State (It (RMS)) (Max) | 785 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 18000A, 20000A |
