ASA025V170B5
Luminus Devices Inc.
Package: Tube
Description: 1700V 25A, TO247-2L, INDUSTRIAL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | No Recovery Time > 500mA (Io) |
| Technology | SiC (Silicon Carbide) Schottky |
| Part Status | Active |
| Mounting Type | Through Hole |
| Qualification | - |
| Package / Case | TO-247-2 |
| Capacitance @ Vr, F | 2943pF @ 0V, 1MHz |
| Supplier Device Package | TO-247-2L |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 75 μA @ 1.7 kV |
| Voltage - DC Reverse (Vr) (Max) | 1700 V |
| Current - Average Rectified (Io) | 74A |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1.6 V @ 25 A |
