UJ3N120065K3S
onsemi
Package: Tube
Description: JFET N-CH 1.2KV 34A TO247-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| FET Type | N-Channel |
|---|---|
| Part Status | Active |
| Power - Max | 254 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Resistance - RDS(On) | 55 mOhms |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247-3 |
| Current Drain (Id) - Max | 34 A |
| Drain to Source Voltage (Vdss) | 1200 V |
| Voltage - Breakdown (V(BR)GSS) | 1200 V |
| Current - Drain (Idss) @ Vds (Vgs=0) | 5 μA @ 1200 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1008pF @ 100V |
