TN3050HP-12L2Y
STMicroelectronics
Package: Cut Tape (CT)
Description: 30 A 1200 V AUTOMOTIVE GRADE SCR
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| SCR Type | Standard Recovery |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
| Voltage - Off State | 1.2 kV |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | HU3PAK |
| Current - Hold (Ih) (Max) | 100 mA |
| Current - Off State (Max) | 5 μA |
| Voltage - On State (Vtm) (Max) | 1.65 V |
| Current - Gate Trigger (Igt) (Max) | 50 mA |
| Current - On State (It (AV)) (Max) | 19 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Current - On State (It (RMS)) (Max) | 30 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 300A, 330A |
