T730N42TOFVTXPSA1
Infineon Technologies
Package: Tray
Description: SCR MODULE 4.2KV 1840A TO-200AC
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Single |
|---|---|
| Part Status | Obsolete |
| Mounting Type | Clamp On |
| Package / Case | TO-200AC |
| Voltage - Off State | 4.2 kV |
| Operating Temperature | -40°C ~ 120°C |
| Number of SCRs, Diodes | 1 SCR |
| Current - Hold (Ih) (Max) | 300 mA |
| Current - Gate Trigger (Igt) (Max) | 300 mA |
| Current - On State (It (AV)) (Max) | 730 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5 V |
| Current - On State (It (RMS)) (Max) | 1840 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 17600A @ 50Hz |
