STGWA80H65DFBAG
STMicroelectronics
Package: Tube
Description: IGBT TRENCH FS 650V 120A TO247
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| IGBT Type | Trench Field Stop |
| Input Type | Standard |
| Gate Charge | 453 nC |
| Part Status | Active |
| Power - Max | 535 W |
| Mounting Type | Through Hole |
| Qualification | AEC-Q101 |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 80A, 10Ohm, 15V |
| Switching Energy | 3.26mJ (on), 2.33mJ (off) |
| Td (on/off) @ 25°C | -/360ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247 Long Leads |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 80A |
| Reverse Recovery Time (trr) | 64 ns |
| Current - Collector (Ic) (Max) | 120 A |
| Current - Collector Pulsed (Icm) | 240 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
