SR3090PTH
Taiwan Semiconductor Corporation
Package: Tube
Description: DIODE ARR SCHOTT 90V 30A TO247AD
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Through Hole |
| Qualification | AEC-Q101 |
| Package / Case | TO-247-3 |
| Diode Configuration | 1 Pair Common Cathode |
| Supplier Device Package | TO-247AD (TO-3P) |
| Current - Reverse Leakage @ Vr | 500 μA @ 90 V |
| Voltage - DC Reverse (Vr) (Max) | 90 V |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 15 A |
| Current - Average Rectified (Io) (per Diode) | 30A |
