SCE200DA80
SanRex Corporation
Package: Tray
Description: SCR MODULE 800V 314A MODULE
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Series Connection - SCR/Diode |
|---|---|
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Voltage - Off State | 800 V |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Number of SCRs, Diodes | 1 SCR, 1 Diode |
| Current - Hold (Ih) (Max) | 140 mA |
| Current - Gate Trigger (Igt) (Max) | 100 mA |
| Current - On State (It (AV)) (Max) | 200 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - On State (It (RMS)) (Max) | 314 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 6000A, 6500A |
