S402ES1
Littelfuse Inc.
Package: Bulk
Description: SEN SCR 400V 1.5A 100 A TO92WB
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| SCR Type | Sensitive Gate |
|---|---|
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Voltage - Off State | 400 V |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Supplier Device Package | TO-92 |
| Current - Hold (Ih) (Max) | 3 mA |
| Current - Off State (Max) | 5 μA |
| Voltage - On State (Vtm) (Max) | 1.7 V |
| Current - Gate Trigger (Igt) (Max) | 100 μA |
| Current - On State (It (AV)) (Max) | 950 mA |
| Voltage - Gate Trigger (Vgt) (Max) | 800 mV |
| Current - On State (It (RMS)) (Max) | 1.5 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 12.5A, 15A |
