S2M0080120B
SMC Diode Solutions
Package: Cut Tape (CT)
Description: DIODE MOSFETS SILICON CARBIDES 1
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| FET Type | N-Channel |
| Vgs (Max) | +20V, -5V |
| Technology | SiCFET (Silicon Carbide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
| Vgs(th) (Max) @ Id | 4V @ 10mA |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Rds On (Max) @ Id, Vgs | 100mOhm @ 20A, 20V |
| Power Dissipation (Max) | 176W (Tc) |
| Supplier Device Package | TO-263-7 |
| Gate Charge (Qg) (Max) @ Vgs | 54 nC @ 20 V |
| Drain to Source Voltage (Vdss) | 1200 V |
| Input Capacitance (Ciss) (Max) @ Vds | 1324 pF @ 1000 V |
| Drive Voltage (Max Rds On, Min Rds On) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) |
