RV7E035ATTCR1
ROHM Semiconductor
Package: Cut Tape (CT)
Description: PCH -30V -3.5A SMALL SIGNAL MOSF
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| FET Type | P-Channel |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 3-XDFN |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 78mOhm @ 3.5A, 10V |
| Power Dissipation (Max) | 1.1W (Ta) |
| Supplier Device Package | DFN1212-3 |
| Gate Charge (Qg) (Max) @ Vgs | 4.3 nC @ 4.5 V |
| Drain to Source Voltage (Vdss) | 30 V |
| Input Capacitance (Ciss) (Max) @ Vds | 305 pF @ 15 V |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 3.5A (Ta) |
