PWB200AA30
SanRex Corporation
Package: Tray
Description: SCR MODULE 300V 314A MODULE
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Structure | Bridge, 3-Phase - All SCRs |
|---|---|
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Voltage - Off State | 300 V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Number of SCRs, Diodes | 3 SCRs |
| Current - Hold (Ih) (Max) | 70 mA |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - On State (It (AV)) (Max) | 200 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2 V |
| Current - On State (It (RMS)) (Max) | 314 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 5400A, 6000A |
