PRFMB200W12
KYOCERA AVX
Package: Bulk
Description: IGBT MODULE, 1IN1, BRAKE CHOPPER
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | - |
| Part Status | Active |
| Power - Max | 961 W |
| Configuration | Single |
| Mounting Type | Chassis Mount |
| NTC Thermistor | No |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | Module |
| Vce(on) (Max) @ Vge, Ic | 2V @ 15V, 200A |
| Current - Collector (Ic) (Max) | 200 A |
| Input Capacitance (Cies) @ Vce | 19000 pF @ 25 V |
| Current - Collector Cutoff (Max) | 1 mA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
