PN3563
Fairchild Semiconductor
Package: Bulk
Description: RF TRANS NPN 15V 1.5GHZ TO-92-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 14dB ~ 26dB |
|---|---|
| Part Status | Obsolete |
| Power - Max | 350mW |
| Mounting Type | Through Hole |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Transistor Type | NPN |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Frequency - Transition | 1.5GHz |
| Supplier Device Package | TO-92-3 |
| Noise Figure (dB Typ @ f) | - |
| Current - Collector (Ic) (Max) | 50mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 8mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 15V |
