PBSS4160PANP-QX
Nexperia USA Inc.
Package: Tape & Reel (TR)
Description: TRANS NPN/PNP 60V 1A 6HUSON
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | Automotive |
|---|---|
| Part Status | Active |
| Power - Max | 370mW |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | 6-UFDFN Exposed Pad |
| Transistor Type | 1 NPN, 1 PNP |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 175MHz, 125MHz |
| Supplier Device Package | 6-HUSON (2x2) |
| Vce Saturation (Max) @ Ib, Ic | 220mV @ 100mA, 1A / 340mV @ 100mA, 1A |
| Current - Collector (Ic) (Max) | 1A |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 290 @ 100mA, 2V / 170 @ 100mA, 2V |
| Voltage - Collector Emitter Breakdown (Max) | 60V |
