ON5088,115
NXP Semiconductors
Package: Bulk
Description: RF TRANS NPN 10V 55GHZ 4-DFP
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 13dB |
|---|---|
| Part Status | Active |
| Power - Max | 136mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-343F |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 55GHz |
| Supplier Device Package | 4-DFP |
| Noise Figure (dB Typ @ f) | 1.1dB @ 12GHz |
| Current - Collector (Ic) (Max) | 40mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 160 @ 10mA, 2V |
| Voltage - Collector Emitter Breakdown (Max) | 10V |
