NXH300B100H4Q2F2S1G
onsemi
Package: Tray
Description: PIM 1500V 250KW Q2BOOST
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench Field Stop |
| Part Status | Active |
| Power - Max | 194 W |
| Configuration | Dual, Common Source |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | 53-PIM/Q2PACK (93x47) |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 73 A |
| Input Capacitance (Cies) @ Vce | 6.323 nF @ 20 V |
| Current - Collector Cutoff (Max) | 800 μA |
| Voltage - Collector Emitter Breakdown (Max) | 1118 V |
