NSS40301CTWG
onsemi
Package: Cut Tape (CT)
Description: TRANS NPN 40V 3A LFPAK4
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 2 W |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | SOT-1023, 4-LFPAK |
| Transistor Type | NPN |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Frequency - Transition | 215MHz |
| Supplier Device Package | LFPAK4 (5x6) |
| Vce Saturation (Max) @ Ib, Ic | 200mV @ 300mA, 3A |
| Current - Collector (Ic) (Max) | 3 A |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 1A, 1V |
| Voltage - Collector Emitter Breakdown (Max) | 40 V |
