NGW30T60M3DFQ
Nexperia USA Inc.
Package: Tube
Description: IGBT TRENCH FS 600V 75A TO-247L
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 130 nC |
| Part Status | Obsolete |
| Power - Max | 285 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 30A, 10Ohm, 15V |
| Switching Energy | 700μJ (on), 400μJ (off) |
| Td (on/off) @ 25°C | 60ns/180ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | TO-247-3L |
| Vce(on) (Max) @ Vge, Ic | 1.7V @ 15V, 30A |
| Reverse Recovery Time (trr) | 110 ns |
| Current - Collector (Ic) (Max) | 75 A |
| Current - Collector Pulsed (Icm) | 90 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
