NESG340033-T1B-A
Renesas Electronics Corporation
Package: Bulk
Description: RF TRANS NPN 5.5V 10GHZ 3-MINI
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Gain | 12dB |
|---|---|
| Grade | - |
| Part Status | Active |
| Power - Max | 480mW |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 10GHz |
| Supplier Device Package | 3-MINIMOLD |
| Noise Figure (dB Typ @ f) | 0.7dB @ 1GHz |
| Current - Collector (Ic) (Max) | 400mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 15mA, 3.3V |
| Voltage - Collector Emitter Breakdown (Max) | 5.5V |
