MSCGL40X120T3AG
Microchip Technology
Package: Tube
Description: PM-IGBT-TFS-SP3F
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench |
| Part Status | Active |
| Configuration | Full Bridge |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | - |
| Supplier Device Package | SP3F |
| Vce(on) (Max) @ Vge, Ic | - |
| Current - Collector (Ic) (Max) | 40 A |
| Current - Collector Cutoff (Max) | 40 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
