MMBT3904H RFG
Taiwan Semiconductor Corporation
Package: Cut Tape (CT)
Description: SOT-23, 60V, 0.2A, NPN TRANSISTO
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Part Status | Active |
| Power - Max | 350 mW |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | NPN |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Frequency - Transition | 300MHz |
| Supplier Device Package | SOT-23 |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 5mA, 50mA |
| Current - Collector (Ic) (Max) | 200 mA |
| Current - Collector Cutoff (Max) | 50nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 10mA, 1V |
| Voltage - Collector Emitter Breakdown (Max) | 40 V |
