MBR1045YD_L2_00601
Panjit International Inc.
Package: Cut Tape (CT)
Description: SURFACE MOUNT SCHOTTKY
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Capacitance @ Vr, F | 496pF @ 4V, 1MHz |
| Supplier Device Package | TO-252AA |
| Current - Reverse Leakage @ Vr | 50 μA @ 45 V |
| Voltage - DC Reverse (Vr) (Max) | 45 V |
| Current - Average Rectified (Io) | 10A |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 600 mV @ 10 A |
