MADP-007448-11410T
MACOM Technology Solutions
Package: Cut Tape (CT)
Description: RF DIODE PIN 100V 200MW SOD-323
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Diode Type | PIN - Single |
|---|---|
| Part Status | Active |
| Current - Max | 150 mA |
| Package / Case | SC-76, SOD-323 |
| Resistance @ If, F | 2Ohm @ 10mA, 100MHz |
| Capacitance @ Vr, F | 0.25pF @ 50V, 1MHz |
| Operating Temperature | 175°C (TJ) |
| Power Dissipation (Max) | 200 mW |
| Supplier Device Package | SOD-323 |
| Voltage - Peak Reverse (Max) | 100V |
