LXP1004-23-2/TR
Microchip Technology
Package: Cut Tape (CT)
Description: RF DIODE PIN 20V 250MW SOT-23-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Diode Type | PIN - 1 Pair Series Connection |
|---|---|
| Part Status | Active |
| Current - Max | 10 mA |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Resistance @ If, F | 600mOhm @ 10mA, 100MHz |
| Capacitance @ Vr, F | 0.75pF @ 20V, 1MHz |
| Operating Temperature | -55°C ~ 125°C |
| Power Dissipation (Max) | 250 mW |
| Supplier Device Package | SOT-23-3 |
| Voltage - Peak Reverse (Max) | 20V |
