LL60P
Shenzhen Slkormicro Semicon Co., Ltd.
Package: Cut Tape (CT)
Description: 25V 100MA 600MV@30MA LL-34
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Technology | Schottky |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | DO-213AC, MINI-MELF, SOD-80 |
| Capacitance @ Vr, F | - |
| Supplier Device Package | LL-34 |
| Reverse Recovery Time (trr) | 2 ns |
| Current - Reverse Leakage @ Vr | 2 μA @ 15 V |
| Voltage - DC Reverse (Vr) (Max) | 25 V |
| Current - Average Rectified (Io) | 100mA |
| Operating Temperature - Junction | - |
| Voltage - Forward (Vf) (Max) @ If | 600 mV @ 30 mA |
