IXBA16N170AHV-TRL
IXYS
Package: Tape & Reel (TR)
Description: IGBT 1700V 16A TO-263HV
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Gate Charge | 65 nC |
| Part Status | Active |
| Power - Max | 150 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Test Condition | 1360V, 10A, 10Ohm, 15V |
| Switching Energy | 1.2mJ (off) |
| Td (on/off) @ 25°C | 15ns/160ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | TO-263HV |
| Vce(on) (Max) @ Vge, Ic | 6V @ 15V, 10A |
| Reverse Recovery Time (trr) | 360 ns |
| Current - Collector (Ic) (Max) | 16 A |
| Current - Collector Pulsed (Icm) | 40 A |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
