IKWH70N65WR6XKSA1
Infineon Technologies
Package: Tube
Description: IGBT TRENCH FS 650V 122A TO247-3
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 269 nC |
| Part Status | Active |
| Power - Max | 290 W |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Test Condition | 400V, 70A, 15Ohm, 15V |
| Switching Energy | 2.2mJ (on), 1.07mJ (off) |
| Td (on/off) @ 25°C | 42ns/378ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | PG-TO247-3-32 |
| Vce(on) (Max) @ Vge, Ic | 1.85V @ 15V, 70A |
| Current - Collector (Ic) (Max) | 122 A |
| Current - Collector Pulsed (Icm) | 210 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
