IKD06N60RC2ATMA1
Infineon Technologies
Package: Cut Tape (CT)
Description: IGBT TRENCH FS 600V 11.7A TO252
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | Trench Field Stop |
|---|---|
| Input Type | Standard |
| Gate Charge | 31 nC |
| Part Status | Active |
| Power - Max | 51.7 W |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Test Condition | 400V, 6A, 49Ohm, 15V |
| Switching Energy | 170μJ (on), 80μJ (off) |
| Td (on/off) @ 25°C | 6ns/129ns |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | PG-TO252-3 |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 6A |
| Reverse Recovery Time (trr) | 98 ns |
| Current - Collector (Ic) (Max) | 11.7 A |
| Current - Collector Pulsed (Icm) | 18 A |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
