GT50N322A
Toshiba Semiconductor and Storage
Package: Tray
Description: IGBT 1000V 50A TO-3P
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| IGBT Type | - |
|---|---|
| Input Type | Standard |
| Part Status | Active |
| Power - Max | 156 W |
| Mounting Type | Through Hole |
| Package / Case | TO-3P-3, SC-65-3 |
| Test Condition | - |
| Switching Energy | - |
| Td (on/off) @ 25°C | - |
| Operating Temperature | 150°C (TJ) |
| Supplier Device Package | TO-3P(N) |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 60A |
| Reverse Recovery Time (trr) | 800 ns |
| Current - Collector (Ic) (Max) | 50 A |
| Current - Collector Pulsed (Icm) | 120 A |
| Voltage - Collector Emitter Breakdown (Max) | 1000 V |
