GSFP0435
Good-Ark Semiconductor
Package: Cut Tape (CT)
Description: MOSFET, N-CH, SINGLE, 35.00A, 40
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 32W (Tc) |
| Configuration | 2 N-Channel (Half Bridge) |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 13mOhm @ 4A, 10V |
| Supplier Device Package | 8-PPAK (5x6) |
| Gate Charge (Qg) (Max) @ Vgs | 10nC @ 10V |
| Drain to Source Voltage (Vdss) | 40V |
| Input Capacitance (Ciss) (Max) @ Vds | 495pF @ 20V |
| Current - Continuous Drain (Id) @ 25°C | 35A (Tc) |
