GSFN3703
Good-Ark Semiconductor
Package: Cut Tape (CT)
Description: MOSFET, N+P, DUAL, 12 -16A, 30 -
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Power - Max | 20W (Tc) |
| Configuration | N and P-Channel Complementary |
| Mounting Type | Surface Mount |
| Qualification | - |
| Package / Case | 8-PowerVDFN |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 20mOhm @ 8A, 10V |
| Supplier Device Package | 8-PPAK (3.15x3.1) |
| Gate Charge (Qg) (Max) @ Vgs | 18nC @ 10V, 48nC @ 10V |
| Drain to Source Voltage (Vdss) | 30V |
| Input Capacitance (Ciss) (Max) @ Vds | 345pF @ 25V, 1250pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 12A (Tc), 16A (Tc) |
