GHXS100B170S-D3
SemiQ
Package: Tube
Description: 1700V, 100A SIC DUAL DIODE MODUL
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Grade | - |
|---|---|
| Speed | No Recovery Time > 500mA (Io) |
| Technology | SiC (Silicon Carbide) Schottky |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Qualification | - |
| Package / Case | SOT-227-4, miniBLOC |
| Diode Configuration | 2 Independent |
| Supplier Device Package | SOT-227 |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 400 μA @ 1.7 kV |
| Voltage - DC Reverse (Vr) (Max) | 1700 V |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1.65 V @ 100 A |
| Current - Average Rectified (Io) (per Diode) | 214A |
