FS3L40R07W2H5FB70BPSA1
Infineon Technologies
Package: Tray
Description: EASY STANDARD
Need More Information?
For additional product parameters, user manuals, or technical support, please contact our sales team.
Product Specifications
| Input | Standard |
|---|---|
| IGBT Type | Trench Field Stop |
| Part Status | Active |
| Configuration | Three Level Inverter |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | - |
| Vce(on) (Max) @ Vge, Ic | 1.81V @ 15V, 20A |
| Current - Collector (Ic) (Max) | 20 A |
| Input Capacitance (Cies) @ Vce | 1940 pF @ 25 V |
| Current - Collector Cutoff (Max) | 18 μA |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
